18
2. Snap the attached Joints B+C into place on the inner side of the window panel.
window panel
joint B+C
inner side
3. Attach the protective grill on the outer side of the window panel to Joint B+C
with included screws.
screws
protective grille
4. Attach the rain shield and rain shield support to the outside of the window panel
by using the included nut, spring washer, washer, and bolts.
Nut
Screws
Washer
Spring washer
Rain Shield
5. Cut Sponge B to the width of your window and attach it to the bottom of the
window sill.
sponge B (adhesive)
To Next Page
