RES-403 Page 17
MOD 26 cannot be used in combination with
MOD 40 ("Temperature OK" signal)
manufactured up to September 2005.
8.8 Wiring diagram with "Temp-
erature reached" signal (MOD 40)
or „Temp. OK“ signal (MOD 46)
MOD 40 cannot be used in combination with
MOD 26 (booster connection) manufactured
prior to September 2005.
MOD 46 cannot be used in combination with
MOD 40.
Additional terminals
in housing cover
for MOD 26 (Booster connection)
BOOSTER
19 20
4
3
2
1
UTOCAL
OUTPUT
HEAT
ALARM
!
+
RES- 403
I
max. 50mA
+24VDC
GND
GND
+24VDC
4
3
2
1
Additional terminals
in housing cover
for MOD 40 (”Temp. reached” signal)
or MOD 46 (”Temp. OK” signal)
AUTOCAL
OUTPUT
HEAT
ALARM
! !
