RES-403 Page 9
6 Technical data
Type of construction Housing for installation in the electrical cabinet
Snaps onto a standard top hat rail (DIN TS35 rail, 35 mm) acc. to DIN EN 50022
Dimensions: 90 x 75 mm; height: 135mm (incl. terminals)
Line voltage All controllers manufactured as of October 2005:
115VAC version: 110VAC -15%…120VAC +10% (equivalent to 94…132VAC)
230VAC version: 220VAC -15%…240VAC +10% (equivalent to 187…264VAC)
400VAC version: 380VAC -15%…415VAC +10% (equivalent to 323…456VAC)
All controllers manufactured as of January 2004 up to September 2005:
115VAC version: 115VAC -15%…120VAC +10% (equivalent to 98…132VAC)
230VAC version: 230VAC -15%…240VAC +10% (equivalent to 196…264VAC)
400VAC version: 400VAC -15%…415VAC +10% (equivalent to 340…456VAC)
All controllers manufactured up to December 2003:
115VAC, 230VAC or 400VAC, tolerance: +10% / -15%
depending on version selected (ª section 12 "How to order" on page 39)
Line frequency 47…63Hz, automatic adjustment to frequencies in this range
Heatsealing band
type and temperature
range
All controllers manufactured as of October 2005:
The temperature range and temperature coefficient settings can also be specified
by means of the ROPEX visualization software (ª section 9.10 "Diagnostic
interface/visualization software (as of October 2005)" on page 30) in addition to
the rotary coding switch (see below):
Temperature range: 200°C, 300°C, 400°C or 500°C
Temperature coefficient: 400…4000ppm (variable setting range)
Five different ranges can be set on the controller with a rotary coding switch:
Temperature coefficient 1100ppm, 0…300°C (e.g. Alloy-A20), default
Temperature coefficient 780ppm, 0…300°C (e.g. Alloy L)
Temperature coefficient 1100ppm, 0…500°C (e.g. Alloy-A20)
Temperature coefficient 780ppm, 0…500°C (e.g. Alloy L)
Temperature coefficient 3500ppm, 0…300°C (e.g. NOREX)
The settings for a temperature coefficient of 780ppm are only available on control-
lers manufactured as of October 2003.
Set point selection
Terminals 16+17
With an external PD-3 or PD-5 precision potentiometer (R = 2kΩ)
0…2kΩ, equivalent to 0…300°C or 0…500°C
Analog output
(actual value)
Terminals 14+15
0…10VDC, Imax = 5mA
Equivalent to 0…300°C or 0…500°C
Accuracy: ±1% add. 50mV
Digital logic levels
Terminals 8, 12, 13
LOW (0V): 0…2VDC
HIGH (24VDC): 12…30VDC (max. current input 6mA)
Reverse polarity-protected
Digital logic levels
„Temp. OK“ signal
(MOD 40)
U
max
=30VDC
I
max
=50mA
U
ON
< 2V (saturation voltage)
