Installation
Page 22 RES-403
actual value output:
The controller is functioning correctly if the tempera-
ture (which corresponds to the signal change at the
analog output) has a harmonious motion, in other
words it must not jump abruptly, fluctuate or deviate
temporarily in the wrong direction. This kind of beha-
vior would indicate that the U
R
measuring wires
have been wired incorrectly.
If an error code is displayed, please proceed as des-
cribed in section 9.12 "Error messages" on page 31.
9. Burn in the heatsealing band (ª section 8.12
"Replacing and "burning in" the heatsealing band"
on page 20) and repeat the AUTOCAL function.
8.13.2 Restart after replacing the heat-
sealing band
To replace the heatsealing band, proceed as described
in section 8.12 "Replacing and "burning in" the heat-
sealing band" on page 20.
Always use a heatsealing band with the cor-
rect alloy, dimensions and copper-plating in
order to avoid malfunctions and overheating.
Continue with section 8.13.1 steps 4 to 9.
The controller is now
ready
!
