SPECIFICATIONS
1"NPT 3/4"NPT
1-1/4"NPSM
1-1/2"NPSM
7 psi (48 kPa)
Flush Valve type bowl
Wash down flush
Automatic flush every
24 hours of non-use
Model Number
Figure
Control stop inlet
Flush Valve inlet
Flush Valve outlet
Supply water
pressure
Shutoff pressure
Rated Flush Volume
Toilet/Urinal type
Trap seal protection
TET1GAR
TET6GAR
Toilet Urinal
TEU1GAR
Min
Max*
15 psi
(103 kPa)
(Flowing)
15 psi (103 kPa)
125 psi
(862 kPa)
125 psi (862 kPa)
125 psi
(862 kPa)
35 psi
(241 kPa)
1.6 G
(6 L)
1.28 G
(4.8 L)
0.5 G (1.9 L)
Automatic flush every
12 hours of non-use
TEU1LAR
TEU1LAX
TEU1UAR
TEU1UAX
0.125 G (0.47 L)
* Water pressures over 80 psi are not recommended for most plumbing fixtures.
NOTE:
32-104˚F (0-40˚C)
34-104˚F (1-40˚C)
Detection range
from the front
7" (H) x 4-9/16"(W) x 3-3/16"(D)
(178 mm (H) x 115 mm (W) x 81 mm (D))
Dimension of cover
Detection time
Ambient temperature
Water temperature
Within 33-1/2" (850 mm)
6 seconds
The type of fixture determines the minimum pressure required for the valve. Consult
fixture manufacturer for the pressure requirement. TET6LA(R)(X), TET6GAR, and TET6UA(R)(X)
require 24" OR LONGER vacuum breakers. The valve will not have the proper detection range
if you use a shorter vacuum breaker.
0.5 G (1.9L)
fuzzy logic
adj. flush vol.
1.0 G (3.8 L)
typical flush vol.
(Static)
ENGLISH
1 G
(3.8 L)
TET1LAR
TET1LAX
TET6LAR
TET6LAX
TET1UAR
TET1UAX
TET6UAR
TET6UAX
