- 8 -
1 8 2
7
6
3
4 5
Close
Open
SPECIFICATIONS
5.
CLEANING THE FILTER SCREEN AND CONSTANT FLOW VALVE
1. Close the stop valve.
2. Remove functional part cover and use the open-close tool to
take out filter and flow regulator.
3. Remove the flow regulator from the filter.
4.
Shake the filter in water to wash away the debris accumulated within.
5. Wash the flow regulator.
6. Connect the flow regulator to the filter.
7. Use an open-close tool to reinstall the filter and flow regulator.
Reinstall the functional part cover.
8. Open the stop valve.
TLE0150** TLE0350** TLE0450**
AC type
ECOPOWER type
DC type
AC 220 V-240 V
50/60 Hz
ECOPOWER
Backup Li-battery
Dry battery
AA x 2
TLE04501*:
0.1 MPa (flowing)
TLE04502*:
0.05 MPa (flowing)
TLE03501*:
0.1 MPa (flowing)
TLE03502*:
0.05 MPa (flowing)
TLE01501*:
0.1 MPa (flowing)
TLE01502*:
0.05 MPa (flowing)
0.75 Mpa (Resting)
130-200 mm (Sensor is self-adusting)
TLE01501*, TLE03501*, TLE04501*: 1.3 L/min
TLE01502*, TLE03502*, TLE04502*: 2.0 L/min
G 1/2
1-40 °C
Model
Type
Power source
voltage
Power
consumption
Minimum
water
pressure
Operating
Standby
1 W
1 W
-
-
-
-
Maximum
water
pressure
Water
supply
pressure
Sensing distance
Operating ambient
temperature
Flow rate
Thread specifications
of water supply
connection
Pay attention to the orientation
of the flow regulator
Do not remove the
flow regulator
