27
A clean way to cut the hole for the servo wire is to cut two
holes with a 1/8" [3.0mm] brass tube sharpened on the end,
then join the holes by removing material between them as
shown in the image. Or just cut carefully with a hobby knife.
Longer
(bottom)
Shorter
(top)
Front
cabane
Aft
cabane
Cross-brace
Hole
Hole
❏
3. Being certain to use threadlocker on all the screws,
loosely fasten the forward and aft cabane struts to the
fuselage with four M3 x 8 Phillips screws. Hint: For inserting
the screws, the fuselage may be placed on its side and the
screws can be lifted on your screwdriver through the holes.
❏
4. Loosely attach the cross-braces to the cabanes with
four more M3 x 8 Phillips screws and M4 nuts and threadlocker.
