Page #18 background image
拓陽精密科 TOYAN ENGINE
17
2. Power Inspection
Make sure that the voltage of 1.5V universal ignition power supply is normal and the storage
power is full.
Make sure that the 7.4V start-up battery voltage is normal and the storage capacity is full.
3. Initial needle setting
The prerequisites here are ample lubrication and cooling. Such a condition is achieved by
having the engine operate on an extremely rich needle-valve setting: the excess oil not only
provides an abundance of lubrication; it also conducts away heat from the surrounding metal
and this is further assisted by the partial evaporation of the alcohol content of the fuel. it is a
four-stroke engine with inlet pipe and carburetor mounted high on the cylinder-head, means
that each charge of rich, cooling, fuel-air mixture is admitted directly into the cylinder, instead
of being pre-heated in a lengthy journey via the crankcase , as in the usual two-stroke model
car unit.
With the help of fan cooling, it can provide excellent operation experience for every enthusiast.
