Toyan Engine FS-S100 Series - Page 20

拓陽精密科技 TOYAN ENGINE
19
4. STARTING
Reminder!
It is very important to set the throttle in the correct position before attempting to start the engine.
It is recommended to set the damper to open at 30% to prevent the engine from opening too much
under "no load" conditions, which will quickly overheat and may seriously damage the engine
piston ring and cylinder liner.
Loosen throttle
screw and adjust
throttle size
Keep the throttle
opening larger
than 1.5mm
