Toyan
5
BASIC STRUCTURE AND COMPONENTS
Engine Hood Idle screw
Cylinder head Throttle rocker arm
Carburetor
Fuel inlet Needle Valve
Start motor Muffler
Engine main body Pressurization mouth
Start belt Flywheel nut
Flywheel
Crankcase
Start gear
