TOYAN
50
This means that each charge of the rich, cooled fuel-air mixture will go directly into the cylinder, rather than being preloaded on a longer stroke
through the crankcase as in typical two-stroke model engines.
heat enters the cylinder. With the assistance of fan cooling, it can provide every enthusiast with an excellent operating experience. You can also buy
TOYAN
A series of water-cooled cooling accessories, so that your engine will be able to maintain long-term stable work.
Notice!
When leaving the factory, each engine has completed the oil needle setting. If you have adjusted the oil needle in the process of use, it is recommended to
adjust the main oil needle to 2.0
circle, and the auxiliary oil needle is adjusted to 1.5 circles. Since the methanol engine needs to maintain the temperature of the glow plug filament to
achieve ignition, when the engine is in a rich oil state when the engine is in a low speed for a long time, the temperature of the filament will gradually
decrease, resulting in difficulty in ignition.
Fast oil.
Since a 4-stroke engine requires a lot of air intake, it is very important to set the throttle screw so that the minimum throttle opening (idle setting)
It is about 1.5mm. For the use and matching of various engine enthusiasts, it is not possible to use force to twist the throttle screw to adjust the size of the
throttle opening, but to relax the throttle screw and then pull the throttle rocker arm to adjust. As shown in the figure:
Loosen the throttle screw,
and then adjust the size of
the throttle
1.5mm
Please keep the damper opening larger
than 1.5mm
