base mount
Make sure the engine mounting surfaces are flush and in the same plane. Improper installation may cause deformation of the
crankcase, bearings, etc., resulting in unstable operation and reduced performance. It is recommended to use a 3.0mm hexagon
socket head screw for fixing the engine. If the existing holes on the engine bracket cannot be completely aligned with the engine
mounting holes, do not force the installation to avoid pressing the screw. If it is installed on other engine platforms, it is
recommended to purchase adjustment pads and install them between the engine bracket and the engine.
Notes on starting
1. Glow plug:
X-Power requires 2 dedicated glow plugs for 4-stroke methanol engines, the glow plugs start the ignition by using
a 1.5 volt power supply. when
When the battery is disconnected, the heat retained in the combustion chamber is still enough to keep the
filament hot enough to keep the engine running. when the compression is reached
dead center, an "automatic" ignition burst will be achieved, while the glow plug remains hot, allowing higher
speed. Conversely, at reduced revs, the glow plugs will get cold, and if the revs are too low, the ignition will stop,
causing the engine to stop, so you can control the engine revs by adjusting the damper to get the best results you
want.
2. Fuel:
Please use quality-assured methanol model motor fuel. Self-configured fuel or fake fuel will greatly reduce the performance and life of
the engine.
Life. Since it is a four-stroke engine, in order to ensure the normal operation of the engine, we require that only fuel containing 20-25%
nitromethane can be used. If high nitro fuel is used, it will have a great impact on the ignition time and cylinder pressure of the engine
and cannot be maintained. Normal and stable work.
