6-1. Specifications

Vehicle specifications

Tire information

Typical tire symbols

Full-size tire

Compact spare tire

Tire size (→P. 482)

DOT and Tire Identification Number (TIN) (→P. 481)

Uniform tire quality grading

For details, see “Uniform Tire Quality Grading” that follows.

Location of treadwear indicators (→P. 368)
