1-7. Safety information

Before driving

Airbag system components

Front airbag sensors

Front passenger occupant

classification system (ECU

and sensors)

Door sensors

Front passenger airbag

Side airbags

Seat belt pretensioners and

force limiters

Side and curtain shield air-

bag sensors

Curtain shield airbags

“PASSENGER AIR BAG

ON” and “PASSENGER

AIR BAG OFF” indicator

lights

SRS warning light

Front passenger’s seat belt

buckle switch

Airbag sensor assembly

Curtain shield airbag sen-

sors

Driver airbag

Driver’s seat belt buckle

switch

Driver’s seat position sen-

sor
