1-9
Removal Procedure
1 Remove the engine hood. (See page 11-XX.)
2 Remove the lower panel and toe board.
3 Drain coolant.
4 Remove the battery.
5 Remove the sedimenter bracket set bolt to free the bracket. (1DZ-II engine vehicle)
6 Disconnect the accelerator wire.
7 Disconnect the fuel hose.
8 Remove the relay block bracket set bolt and free the relay block.
9 Remove the battery set plate.
10 Remove the air cleaner and air inlet.
11 Remove the exhaust cover plate.
12 Disconnect the exhaust pipe.
13 Disconnect the water hose.
14 Disconnect the T/C cooler hose. [Point 1]
15 Remove the radiator and fan shroud.
16 Remove the under cover.
17 Remove the wiring and wire harness clamps around the engine.
18 Remove the oil pump set bolt and free it.
19 Remove the cover plate. [Point 2]
20 Remove the 6 drive plate set bolts. [Point 3]
21 Remove the engine mount nuts.
22 Slightly hoist the engine. [Point 4]
23 Support the torque converter housing with wooden blocks.
24 Separate the torque converter housing and engine. [Point 5]
25 Remove the engine ASSY.
26 Remove the drive plate.
27 Remove the torque converter end plate.
28 Remove the starting motor.
Installation Procedure
The installation procedure is the reverse of the removal procedure.
Note:
• Apply sealant (08833-76002-71 (08833-00080)) before tightening the drive plate set bolt (for connecting
engine and crankshaft).
• Bleed air from the fuel system after installation of the engine ASSY. (1DZ-II engine vehicle)
(See page 1-18.)
