354
4-3. Do-it-yourself maintenance
Remove the light bulb.
When installing, reverse the step
s listed.
Rear turn signal light
s
On some models, remove a clip
and partly remove the cover
.
T
o prevent damage to the vehicle,
cover the tip of the screwdriver
with a rag.
T
urn the bulb base
counterclock-
wise.
STEP
4
STEP
5
STEP
1
STEP
2
