5
When t
roubl
e arises
527
5-2. Steps to take in an emergency
T
aking out the spare tire
Loosen the center fastene
r that
secures the sp
are tire.
Replacing a flat tire
Chock the tires.
ITO52P106
STEP
1
Flat tire
Wheel chock positions
Front
Lef
t-hand side
Behind the re
ar right-
hand side tire
Right-hand side
Behind the rear left-hand
side tire
Rear
Lef
t-hand side
In front of the front right-
hand side tire
Right-hand side
In front of the front lef
t-hand side tire
521
523
Table of Contents
Before Driving
2
Table of Contents
2
Table of Contents
3
Exterior
9
Pictorial Index
9
Interior
11
Instrument Panel
15
Luggage Compartment
21
Accessories, Spare Parts and Modification of Your Toyota
23
Noise from under Vehicle after Turning off the Hybrid System
23
Installation of a Mobile Two-Way Radio System
24
Scrapping of Your Toyota
24
Arrows Indicating Operations
26
Safety Symbol
26
Symbols Used in Illustrations
26
Symbols Used Throughout this Manual
26
Hybrid System
28
During Normal Driving
29
When Accelerating Sharply
29
When Braking (Regenerative Brake)
29
When Stopped/During Take-Off
29
Charging the Battery
30
Conditions in Which the Gasoline Engine May Not Stop
30
Maintenance, Repair, Recycling, and Disposal
31
Sounds and Vibrations Specific to a Hybrid Vehicle
31
High Voltage Components
32
Emergency Shut off System
33
Hybrid Battery Air Vent
33
Driving Efficiently
34
Eco Drive Monitor
34
Hybrid System Operating Condition
34
When Accelerating
34
Checking Fuel Consumption
35
When the Desired Speed Is Reached
35
Hybrid Warning Message
37
High Voltage Precautions
38
Hybrid Battery (Traction Battery)
38
Key Information
41
Keys
41
Using the Mechanical Key
41
Key Number Plate
42
Smart Key System (with Entry Function)
43
Unlocking and Locking the Doors
44
Back Door (Vehicles with Entry Function of Front and Back Doors)
45
Antenna Location and Effective Range
46
Effective Range
47
Operation Signals
47
When the Door Cannot be Locked Using the Topside Sensor Area
47
Switching the Door Unlock Function
48
Battery-Saving Function
49
To Operate the System Properly
50
Note for the Smart Key System
50
Alarms and Warning Indicators
52
Smart Key System (Without Entry Function)
57
Opening, Closing and Locking the Doors and Back Door
63
Wireless Remote Control
63
Panic Mode
64
Door Lock Buzzer (Vehicles with Entry Function)
64
Electronic Key Battery Depletion
64
Conditions Affecting Operation
65
Security Feature
66
If the Wireless Remote Control Does Not Operate Properly
66
Side Doors
67
Door Lock Switch
67
Inside Lock Button
67
Locking the Front Doors from the Outside Without a Key
68
Rear Door Child-Protector Lock
68
Automatic Door Locking and Unlocking Systems
69
Setting and Canceling the Functions
69
Back Door
72
Unlocking and Locking the Back Door
72
Opening the Back Door from Outside the Vehicle
72
Luggage Compartment Light
73
When Closing the Back Door
73
If the Back Door Opener Is Inoperative
73
Adjustable Components (Seats, Mirrors, Steering Wheel)
78
Front Seats
78
Active Head Restraints
78
Rear Seats
80
Remove the Seat Belt from the Guide
80
Returning Rear Seatbacks
80
Head Restraints
82
Adjusting the Height of the Head Restraints
83
Adjusting the Rear Center Seat Head Restraint
83
Removing the Head Restraints
83
Installing the Head Restraints
84
Front and Rear Center Seats
84
Rear Outboard Seats
84
Seat Belts
85
Correct Use of the Seat Belts
85
Fastening and Releasing the Seat Belt
85
Seat Belt Pretensioners (Front Seats)
86
Pre-Collision Seat Belts
86
Adjusting the Height of the Belt (Front Seats)
86
Emergency Locking Retractor (ELR)
87
Automatic Locking Retractor (ALR)
87
Pregnant Women
87
People Suffering Illness
88
Child Seat Belt Usage
88
Replacing the Belt after the Pretensioner Has Been Activated
88
Seat Belt Extender
88
Steering Wheel
92
Inside Rear View Mirror
93
Auto Anti-Glare Inside Rear View Mirror
93
Manual Anti-Glare Inside Rear View Mirror
94
To Prevent Sensor Error
95
Vehicles with Garage Door Opener
95
Outside Rear View Mirrors
96
Folding the Mirrors
96
Opening and Closing the Windows and Moon Roof
98
Power Windows
98
Lock Switch
98
Jam Protection Function
99
Moonroof with Solar Panel
100
If the Moon Roof Cannot be Closed
102
To Reduce Moon Roof Wind Noise
102
Sunshade
102
Opening the Fuel Tank Cap
104
Before Refueling the Vehicle
104
Closing the Fuel Tank Cap
105
Fuel Types
105
Fuel Tank Capacity
105
Theft Deterrent System
108
Immobilizer System
108
Conditions that May Cause the System to Malfunction
108
Theft Prevention Labels (U.S.A.)
110
Safety Information
111
Correct Driving Posture
111
SRS Airbags
113
Front Airbags
113
Driver Airbag/Front Passenger Airbag
113
Knee Airbag
113
Side and Curtain Shield Airbags
114
Airbag System Components
115
If the SRS Airbags Deploy (Inflate)
116
SRS Airbag Deployment Conditions (Front Airbags)
117
SRS Airbag Deployment Conditions (Side and Curtain Shield Airbags)
117
Types of Collisions that May Not Deploy the SRS Airbag (Front Airbags)
118
Types of Collisions that May Not Deploy the SRS Airbag
119
Front Passenger Occupant Classification System
126
There Is a Malfunction in the System
129
Child Restraint Systems
132
Points to Remember
132
Types of Child Restraints
132
Rear Facing ⎯ Infant Seat/Convertible Seat
132
Forward Facing ⎯ Convertible Seat
133
Booster Seat
133
When Installing Child Restraint System on the Front Passenger Seat
134
Selecting an Appropriate Child Restraint System
134
Installing Child Restraints
137
Child Restraint LATCH Anchors
137
Installation with LATCH System
138
Anchor Bracket
138
Installing Child Restraints Using a Seat Belt
140
Removing a Child Restraint System Installed with a Seat Belt
143
Child Restraint Systems with a Top Tether Strap
144
Outside (Foldable Type)
144
Outside (Non-Foldable Type)
144
Center
144
Foldable Type
145
Non-Foldable Type
145
Laws and Regulations Pertaining to Anchors
146
Driving Procedures
149
Driving the Vehicle
149
Stopping
149
Parking the Vehicle
149
Starting on a Steep Incline
150
Driving in the Rain
150
Breaking in Your New Toyota
150
Operating Your Vehicle in a Foreign Country
151
For Efficient Use
151
Drive Your Vehicle Smoothly
151
Avoid Repeated Acceleration
151
Environmentally Friendly Driving
152
Brake Actuator
152
When Braking the Vehicle
152
Power (Ignition) Switch
161
Starting the Hybrid System
161
Stopping the Hybrid System
162
Changing “POWER” Switch Mode
163
If the Hybrid System Does Not Start
164
If the “READY” Indicator Does Not Come on
164
When the “POWER” Switch Indicator Flashes in Amber
164
Auto Power off Function
164
When Leaving the Vehicle
165
Auto “P” Position Function
165
Leak Detection Pump
166
EV-Drive Mode
167
Situations in Which EV-Drive Mode Cannot be Turned on
168
Automatic Cancelation of EV-Drive Mode
168
Possible Driving Distance When Driving in EV-Drive Mode
169
Fuel Economy
169
Transmission
170
Shifting the Shift Lever
170
Shift Position Uses
171
Selecting a Driving Mode
171
Eco Driving Mode
172
Power Mode
172
Changing Shift Ranges to “P” Position
173
Using Engine Brake
173
Reverse Warning Buzzer
174
When in Heavy Traffic
174
If the System Malfunctions
174
Alarms
175
Turn Signal Lever
177
Turn Signals Can be Operated When
177
If the Indicators Flash Faster than Usual
177
Parking Brake
178
Usage in Winter Time
178
Horn
179
Instrument Cluster Gauges and Meters
180
Touch Tracer Display
181
MPH or Km/H Button
182
Instrument Panel Light Control
183
Indicators and Warning Lights
184
Indicators
185
Warning Lights
186
Multi-Information Display
187
Switching the Display
188
Energy Monitor
189
Hybrid Battery (Traction Battery) Status
190
Hybrid System Indicator
191
5-Minute/1-Minute Interval Fuel Consumption Display
193
Switching between 5-Minute and 1-Minute Intervals
193
5-Minute Interval Fuel Consumption
194
1-Minute Interval Fuel Consumption
195
Fuel Consumption History Display
196
Odometer/Trip Meter/Distance to Empty
197
Resetting the Best Consumption
197
Distance to Empty
198
Odometer
198
Trip Meter
198
Setting up the Displays
199
Selecting 12H/24H Clock Display
200
Setting the Clock
200
Selecting the Language
201
Turning off the Multi-Information Display
202
Eco Driving Indicator Light
203
Returning to the Previous Screen
203
System Check Display
203
Vacuum Fluorescent Display
203
Driving in Eco Driving Mode
204
When the 12 Volt Battery Is Disconnected
204
Operating the Lights and Windshield Wipers
205
Headlight Switch
205
Turning on the High Beam Headlights
206
Daytime Running Light System
206
Headlight Control Sensor
206
Automatic Headlight Leveling System (Vehicles with LED Headlights)
207
Fog Light Switch
208
Windshield Wipers and Washer
209
The Windshield Wipers and Washer Can be Operated When
210
If no Windshield Washer Fluid Sprays
210
Rear Window Wiper and Washer
211
The Rear Window Wiper and Washer Can be Operated When
211
Headlight Cleaner Switch
212
The Headlight Cleaner Can be Operated When
212
Windshield Washer Linked Operation
212
Cruise Control
213
Set the Vehicle Speed
213
Using Other Driving Systems
213
Adjusting the Speed Setting
214
Canceling and Resuming Regular Acceleration
214
Accelerating
215
Automatic Cruise Control Cancelation
215
If the Cruise Main Indicator Light Flashes
215
Dynamic Radar Cruise Control
217
Adjusting the Set Speed
219
When the Set Speed Is Shown in “Km/H”
219
When the Set Speed Is Shown in “MPH”
219
Canceling and Resuming the Speed Control
220
Changing the Vehicle-To-Vehicle Distance
220
Driving in Vehicle-To-Vehicle Distance Control Mode
221
Approach Warning
222
Example of Constant Speed Cruising
222
Example of Deceleration Cruising
222
Example of Follow-Up Cruising
222
Selecting Conventional Constant Speed Control Mode
223
Automatic Cancelation of Vehicle-To-Vehicle Distance Control
224
Dynamic Radar Cruise Control Can be Set When
224
Switching Modes
224
Automatic Cancelation of Constant Speed Control
225
Radar Sensor and Grille Cover
225
Vehicle-To-Vehicle Distance Settings
225
Rear View Monitor System
230
Displayed Area
231
Switching the Screen (Vehicles Without Navigation System)
231
Rear View Monitor System Camera
232
Smear Effect
232
Lane Departure Warning Function
234
Lane Keeping Assist Function
234
LKA (Lane-Keeping Assist)
234
Turning the LKA System on
235
Operating Conditions for each Function
236
Indication on the Multi-Information Display
237
Temporary Cancellation of the LKA System Functions
238
No-Handed Driving Warning
239
When the Vehicle Has Been Parked in the Sun
239
Hill-Start Assist Control
242
Hill-Start Assist Control Operating Conditions
242
Hill-Start Assist Control Buzzer
243
If the Slip Indicator Comes on
243
Driving Assist Systems
244
EPS Operation Sound
245
When the Enhanced VSC/TRAC Is Operating
245
Reduced Effectiveness of EPS
246
Pre-Collision Brake Assist
248
Pre-Collision Braking
248
Pre-Collision System
248
Disabling Pre-Collision Braking
249
Radar Sensor
249
Obstacles Not Detected
250
Driving Information Cargo and Luggage
254
Capacity and Distribution
255
Example on Your Vehicle
256
Seating Capacity
259
Total Load Capacity
259
Towing Capacity
259
Vehicle Load Limits
259
Pre-Winter Preparations
260
Winter Driving Tips
260
Before Driving the Vehicle
261
When Driving the Vehicle
261
When Parking the Vehicle
261
Selecting Tire Chains
262
Regulations on the Use of Tire Chains
263
Tire Chains
263
Trailer Towing
265
Dinghy Towing
266
Using the Air Conditioning System and Defogger
267
Air Conditioning System
267
Using the Automatic Mode
268
Adjusting the Settings
268
Adjusting the Temperature Setting
268
Adjusting the Fan Speed
268
Changing the Air Outlets
269
Switching between Outside Air and Recirculated Air Modes
270
Defogging the Windshield
271
Micro Dust and Pollen Filter
271
Adjusting the Position of the Air Outlets
272
Center Outlets
272
Right and Left Side Outlets
272
Opening and Closing the Air Outlets
273
Using the System in Recirculated Air Mode
274
Window Defogger Feature
274
When Eco Driving Mode Is on
275
Plasmacluster
275
Air Conditioning Odors
275
Using the Steering Wheel Climate Remote Control Switches
277
Changing the Recirculated Air Mode
278
When Operating the Steering Switches
278
Solar Ventilation System
279
Activating the Solar Ventilation System
279
Efficient Use of the Solar Ventilation System
280
Operating Conditions
280
When Using the Solar Ventilation System
280
Noises When Using the Solar Ventilation System
280
Remote Air Conditioning System
282
Activating the Remote Air Conditioning System
282
Using the Remote Air Conditioning System Effectively
282
Rear Window and Outside Rear View Mirror Defoggers
286
Using the Audio System
288
Audio System Type
288
Using Cellular Phones
289
Using the Radio
291
Setting Station Presets
292
Scanning Radio Stations
292
Scanning the Preset Radio Stations
292
Scanning All Radio Stations Within Range
292
XM Satellite Radio
293
Receiving XM Satellite Radio
293
Presetting XM Satellite Radio Channels
293
Changing the Channel Category
293
Scanning XM Satellite Radio Channels
294
Displaying Text Information
294
Silencing the Sound (Type B Only)
295
Reception Sensitivity
295
XM Subscriptions
296
Radio ID
296
Satellite Tuner
296
If the Satellite Radio Does Not Operate Normally
297
Certifications for the Radio Tuner
298
Using the CD Player
300
Loading a Cds
301
Loading Multiple Cds (Type a Only)
301
Ejecting Cds
302
Selecting a CD (with a CD Changer)
302
To Select a CD to Play
302
To Scan Loaded Cds
302
Selecting a Track
303
Fast Forwarding and Rewinding Tracks
303
Scanning a CD
303
Random Playback
303
Repeating a Track or a Disc
304
Canceling Random, Repeat and Scan Playback
305
Error Messages
305
Discs that Can be Used
305
CD Player Protection Feature
305
Playing Back MP3 and WMA Discs
308
Loading and Ejecting MP3 and WMA Discs
308
Selecting and Scanning a Folder
309
Selecting Folders One at a Time
309
Selecting One File at a Time
309
Fast Forwarding and Reversing Files
309
MP3 and WMA Files
312
MP3 File Compatibility
312
WMA File Compatibility
313
Compatible Media
313
Compatible Disc Formats
313
File Names
314
Multi-Sessions
314
ID3 and WMA Tags
314
MP3 and WMA Playback
314
Extensions
315
Playback
315
Optimal Use of the Audio System
316
Using the AUDIO CONTROL Function
316
Changing Modes
316
Adjusting Sound Quality
317
Adjusting the Automatic Sound Levelizer (ASL)
318
Using the AUX Adapter
319
Operating Portable Audio Devices Connected to the Audio System
319
When Using a Portable Audio Device Connected to the Power Outlet
319
Turning on the Power
320
Changing the Audio Source
320
Using the Steering Switches
320
Adjusting the Volume
321
Selecting a Radio Station
321
Selecting a Disc or Folder in the CD Player
321
Canceling Automatic Selection of a Radio Station
322
Using the Hands-Free System (for Cellular Phone)
323
About Bluetooth
324
Compatible Models
324
When Transferring Ownership of the Vehicle
324
Using the Hands-Free System
326
Operating the System by Using a Voice Command
329
Using the Hands-Free System for the First Time
329
Menu List of the Hands-Free System
331
Normal Operation
331
Using a Short Cut Key
333
Automatic Adjustment of Volume
334
When Using a Voice Command
334
Making a Phone Call
335
Receiving a Phone Call
335
Using a Call History Memory
335
Dialing by Inputting a Name
336
Dialing by Inputting a Number
336
Speed Dialing
337
When Receiving a Phone Call
337
Transferring a Call
338
Using the Call History Memory
339
Call History
340
When Talking on the Phone
340
Functions and Operation Procedures
341
Setting a Cellular Phone
341
Registering a Cellular Phone
342
Selecting a Cellular Phone to be Used
342
Changing a Registered Name
343
Listing the Registered Cellular Phones
344
Deleting a Cellular Phone
345
Changing the Passkey
346
Security and System Setup
347
Security Setting Items and Operation Procedure
347
System Setup Items and Operation Procedure
347
Setting or Changing the PIN
348
Locking or Unlocking the Phone Book
349
Setting Voice Guidance Volume
349
When the Phone Book Is Locked
350
Using the Phone Book
351
Adding a New Phone Number
352
Inputting a Telephone Number by Using a Voice Command
352
Inputting a Phone Number
353
Transferring Data from the Cellular Phone
353
Selecting a Phone Number from Outgoing or Incoming Call History
354
Setting Speed Dials
355
Deleting Registered Data
358
Deleting Speed Dials
359
Listing the Registered Data
359
Using the Interior Lights
360
Interior Lights List
360
Personal/Interior Light Main Switch
361
Personal/Interior Lights
362
Interior Light
362
To Prevent 12 Volt Battery Discharge
363
Using the Storage Features
364
List of Storage Features
364
Glove Boxes
365
Glove Box Light (Lower Glove Box Only)
365
Console Box
366
Tray in the Console Box (Type a Only)
366
Overhead Console (Vehicles Without the Moon Roof)
367
Card Holder
368
Cup Holders
369
Removing the Cup Holder (Front Type B Only)
370
Bottle Holders
371
Auxiliary Box
372
Other Interior Features
373
Sun Visors
373
Vanity Mirror
374
Outside Temperature Display
375
Power Outlets
376
Seat Heaters
378
Armrest
380
Floor Mats
381
Luggage Compartment Features
382
Cargo Hooks
382
Removing the Luggage Cover
384
Luggage Cover
384
Stowing the Luggage Cover
385
When Not Using the Luggage Cover
385
Garage Door Opener
386
Programming the Homelink
386
Programming a Rolling Code System (for U.S.A. Owners)
388
Programming an Entry Gate
389
Programming Other Devices
389
Reprogramming a Button
389
Operating the Homelink
390
Erasing the Entire Homelink Memory (All Three Programs)
390
Before Programming
391
Safety Connect
392
System Components
392
Subscription
393
Automatic Collision Notification
393
Stolen Vehicle Location
393
Safety Connect Services Information
394
Languages
394
When Contacting the Response Center
394
Safety Connect LED Light Indicators
395
Safety Connect Services
395
Emergency Assistance Button (“SOS”)
396
Roadside Assistance
396
Safety Information for Safety Connect
397
Exposure to Radio Frequency Signals
397
Maintenance and Care Cleaning and Protecting the Vehicle's Exterior
400
Aluminum Wheels
401
Automatic Car Washes
401
High Pressure Automatic Car Washes
401
To Prevent Paint Deterioration and Corrosion on the Body
401
Cleaning and Protecting the Vehicle’s Interior
403
Cleaning the Leather Areas
403
Synthetic Leather Areas
403
Caring for Leather Areas
404
Shampooing the Carpets
404
General Maintenance
406
Maintenance Requirements
406
Scheduled Maintenance
406
Engine Compartment
408
General Maintenance
408
Vehicle Interior
409
Vehicle Exterior
410
Emission Inspection and Maintenance (I/M) Programs
411
If the Malfunction Indicator Lamp Comes on
411
If Your Vehicle Does Not Pass the I/M Test
411
Do-It-Yourself Service Precautions
412
Do-It-Yourself Maintenance
412
Hood
416
Positioning a Floor Jack
419
Engine Compartment
421
Engine Oil
422
Checking the Engine Oil
422
Adding Engine Oil
423
Engine Oil Consumption
424
After Changing the Engine Oil (U.S.A. Only)
424
Engine/Power Control Unit Coolant
426
Engine Coolant Reservoir
426
Power Control Unit Coolant Reservoir
426
If the Coolant Level Drops Within a Short Time after Replenishing
426
Coolant Selection
427
Radiator and Condenser
428
Brake Fluid
428
Checking Fluid Level
428
Adding Fluid
429
Brake Fluid Can Absorb Moisture from the Air
429
Washer Fluid
430
12 Volt Battery
432
Location
432
Removing the 12 Volt Battery Cover
432
12 Volt Battery Exterior
433
Before Recharging
433
After Recharging/Reconnecting the 12 Volt Battery
434
Tires
437
Checking Tires
437
Tire Rotation
437
Installing Tire Pressure Warning Valves and Transmitters
438
Initializing the Tire Pressure Warning System
438
The Tire Pressure Warning System
438
How to Initialize the Tire Pressure Warning System
439
Registering ID Codes
440
When to Replace Your Vehicle’s Tires
440
Replacing Tires and Wheels
440
Tire Life
441
Low Profile Tires
441
Maximum Load of Tire
441
Tire Types
442
Summer Tires
442
All Season Tires
442
Snow Tires
442
Routine Tire Inflation Pressure Checks
443
Tire Pressure Warning System Certification
444
Tire Inflation Pressure
447
Inspection and Adjustment Procedure
448
Tire Inflation Pressure Check Interval
448
Effects of Incorrect Tire Inflation Pressure
449
Instructions for Checking Tire Inflation Pressure
449
Wheels
451
Wheel Selection
451
Aluminum Wheel Precautions
451
When Replacing Wheels
452
Air Conditioning Filter
453
Removal Method
453
Cleaning Method
454
Replacement Method
455
Checking Interval
455
If Air Flow from the Vents Decreases Dramatically
455
Electronic Key Battery
456
Replacing the Battery
456
If the Electronic Key Battery Is Discharged
457
Use a CR1632 Lithium Battery
457
Checking and Replacing Fuses
458
Left Side Instrument Panel
458
Fuse Layout and Amperage Ratings
461
Engine Compartment
461
After a Fuse Is Replaced
467
If There Is an Overload in the Circuits
467
Light Bulbs
468
Prepare a Replacement Light Bulb
468
Vehicles with Halogen Headlights
469
Rear Bulb Locations
469
Replacing Light Bulbs
470
Headlight Low Beams (Halogen Bulbs)
470
Headlight High Beams
472
Vehicles with LED Headlights
472
Parking Lights
473
Front Side Marker Lights
474
Front Fog Lights (Vehicles with LED Headlights)
475
Front Turn Signal Lights
476
Rear Turn Signal Lights and Back-Up Lights
477
License Plate Lights
478
Lights Other than the above
478
Condensation Build-Up on the Inside of the Lens
479
LED Lights
479
Installing the Engine under Cover Clip
479
Essential Information
481
Emergency Flashers
481
If Your Vehicle Needs to be Towed
482
Before Towing
482
Emergency Towing
482
Towing Eyelet
483
Emergency Towing Procedure
483
Installing Towing Eyelet
484
Towing with a Sling-Type Truck
485
Towing with a Wheel Lift-Type Truck
486
Using a Flat Bed Truck
487
If You Think Something Is Wrong
488
Visible Symptoms
488
Audible Symptoms
488
Operational Symptoms
488
Event Data Recorder
489
In a Crash or a Near Car Crash Event
489
Disclosure of the Data
490
Steps to Take in an Emergency if a Warning Light Turns on or a Warning Buzzer Sounds
491
Front Passenger Detection Sensor and Passenger Seat Belt Reminder
498
The Tire Pressure Warning Light May Turn on Due to Natural Causes
498
When a Tire Is Replaced with a Spare Tire
498
When the Tire Pressure Warning Light Comes on
498
If the Tire Pressure Warning System Is Inoperative
499
Maintenance of the Tires
501
If a Warning Message Is Displayed
503
Before Jacking up the Vehicle
519
If You Have a Flat Tire
519
Location of the Spare Tire, Jack and Tools
519
Compact Spare Tire
520
Taking out the Jack
521
Replacing a Flat Tire
522
Taking out the Spare Tire
522
Installing the Spare Tire
524
Stowing the Flat Tire
526
The Compact Spare Tire
527
Tread Life
527
Jack Point Guide
528
When Using the Compact Spare Tire
528
If the Hybrid System will Not Start
533
Emergency Start Function
534
If You Lose Your Keys
535
If the Electronic Key Does Not Operate Properly
536
Locking and Unlocking the Doors
536
If the 12 Volt Battery Is Discharged
538
Connecting the Jumper Cables
539
Correction Procedures
543
If Your Vehicle Overheats
543
Overheating
546
If the Vehicle Becomes Stuck
548
Dimensions and Weight
550
Specifications Maintenance Data (Fuel, Oil Level, Etc.)
550
Vehicle Identification Number
551
Engine Number and Electric Motor (Traction Motor) Number
552
Engine Oil Selection
554
How to Read Oil Container Labels
555
Fuel Information
562
Fuel Tank Opening for Unleaded Gasoline
562
Gasoline Quality
562
If Your Engine Knocks
562
Gasoline Quality Standards
563
Toyota Recommends the Use of Cleaner Burning Gasoline
563
Toyota Does Not Recommend Blended Gasoline
564
Toyota Does Not Recommend Gasoline Containing MMT
564
Standard Tire
566
Tire Information
566
Typical Tire Symbols
566
Typical DOT and Tire Identification Number (TIN)
568
Tire Size
569
Typical Tire Size Information
569
Tire Dimensions
570
Tire Section Names
570
DOT Quality Grades
571
Treadwear
571
Uniform Tire Quality Grading
571
Temperature A, B, C
572
Traction AA, A, B, C
572
Glossary of Tire Terminology
573
Customization
581
Customizable Features
581
Customization Customizable Features
581
Initialization Items to Initialize
587
Reporting Safety Defects for U.S. Owners
589
Seat Belt Instructions for Canadian Owners (in French)
590
Abbreviation List
592
Alphabetical Index
593
What to Do if
603
Gas Station Information
608
Other manuals for Toyota Prius 2010
User Guide
33 pages
Repair Manual
452 pages
Quick Reference Guide
15 pages
Manual
23 pages
Owner's Manual
8 pages
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Toyota Prius 2010 and is the answer not in the manual?
Ask a question
Toyota Prius 2010 Specifications
General
Brand
Toyota
Model
Prius 2010
Category
Automobile
Language
English
Related product manuals
Toyota 2014 Prius
640 pages
Toyota 2010 Prius
635 pages
Toyota PRIUS 2014
688 pages
Toyota PRIUS 2016
56 pages
Toyota 2016 Prius
800 pages
Toyota 2011 Prius
651 pages
Toyota 2015 Prius
660 pages
Toyota Prius 2019
828 pages
Toyota 2012 Prius
704 pages
Toyota 2014 Prius V
5 pages
Toyota Prius C 2013
18 pages
Toyota 2013 Prius c
549 pages
To Next PageTo Next PageTo Previous PageTo Previous Page
Loading...
Need help?
General
