TOYOTA MY22 TUNDRA 2022 - DASHCAM (Digital Video Recorder)
Procedure
(c) Feed the Dashcam harness through to
the open Map Light Console area.
(Fig. 7-3)
(d) Pull the majority of the wire length
through to the console area so that the
camera is ready to mount on to the
window plate. (Fig. 7-4)
(e) Locate the existing pre-wire harness in
the drivers side of the map light /
overhead console opening. (Fig. 7-5)
(f) Disengage wire harness clip and connect the
harness into this prewired power connector.
Reconnect wire harness clip and cover with
the provided foam tape, and secure any
excess length with a zip tie against the
existing power supply harness.
(Fig. 7-6)
Fig. 7-4
Fig. 7-5
