Toyota Sienna 2021 - Instrument Cluster; Indicator Symbols

4
OVERVIEW
Instrument cluster
For details, refer to “Warning lights and indicators,” Section 2, 2021 Owner’s
Manual.
Hybrid System Indicator
Hybrid System Indicator
Speedometer
Speedometer
Multi-Information Display
Clock
Outside temperature
Outside temperature
Clock
Multi-Information Display
Engine coolant temperature
Engine coolant temperature
Odometer, trip meter
and oil maintenance
Odometer, trip meter and oil maintenance
Shift position
and shift range
Shift position and shift range
Fuel gauge
Fuel gauge
AIR BAG ON/OFF indicator
1
Airbag SRS warning
1
Brake hold operating indicator
1,2
Automatic High Beams (AHB)
indicator
Anti-lock Brake System (ABS)
warning
1
BSM outside rear view mirror
indicators
1,4
BSM (Blind Spot Monitor) OFF
indicator
4
1
If the indicator does not turn off within a few seconds of starting the vehicle, there may be a
malfunction. Have the vehicle inspected by your Toyota dealer.
2
If the indicator flashes, there may be a malfunction. Refer to the Owner’s Manual.
3
If the indicator flashes, it indicates that the system is operating.
4
If equipped.
5
Refer to section PKSB (Parking Support Braking function) in the Owner’s Manual.
VEHICLES EQUIPPED WITH 4.2-in DISPLAY
VEHICLES EQUIPPED WITH 7-in DISPLAY
Indicator symbols
Service indicators and warning lights
