TP-Link Archer Air E5 User Manual

5
Chapter 1
Get to Know About Your Extender
1. 2. 1. LED Explanation
You can check the extender’s working status by following the LED Explanation table.
Name Status Indication
Off
The extender is not powered or not powered by a
standard power source.
Quickly
pulsing
blue
The system is starting up or firmware upgrade is in
progress.
Quickly
pulsing red
WPS connection failed. The extender will return to
unconnected status in one minute.
Slowly
pulsing
blue
WPS Connection is in progress
Slowly
pulsing red
The extender is not connected to the router’s wireless
network.
Solid blue
The extender is connected to the router’s wireless
network and is in a suitable location.
Solid red
The extender is connected with a weak signal. Try
relocating it closer to your router.
1. 2. 2. Button Description
Button Description
(WPS)
Press the WPS button on your router. Within 2 minutes, press the WPS
button on the extender for 1 second. The WPS LED should change
from pulsing blue to solid blue, indicating successful connection.
Reset
With the extender powered on, use a pin (provided) to press the RESET
button for 5 seconds to reset the extender to its factory default settings.

TP-Link Archer Air E5 Specifications

General

Type	Network repeater
Maximum transfer distance	- m
Reset button	Yes
Certification	FCC, RoHS
Mounting type	Wall
Product color	White
Output current	2 A
Output voltage	12 V
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	8 mm
Width	148 mm
Height	210 mm
