Chapter 1
Get to Know About Your Router
Status Indication
Quickly Pulsing Red WPS connection failed.
1. 2. 2. Bottom Panel
LA
AN
Reset
Power Port
The following parts (view from left to right) are located on the back panel.
Button and Port Explanation
Item Description
LAN Port For connecting your PC or other wired devices to the router.
Reset Button
Press and hold the button until the Power LED blinks to reset the router to its
factory default settings.
Power Port For connecting the router to a power socket via the provided power adapter.
WAN Port For connecting to a modem or an Ethernet outlet.
To Next Page
