Archer D5 AC1200 Wireless Dual Band Gigabit ADSL2+ Modem Router User Guide
10
The LEDs of LAN port which you link to the device and the LEDs on your PC's adapter should
be lit.
2) Is the TCP/IP configuration for your PC correct?
If the modem router's IP address is 192.168.1.1, your PC's IP address must be within the
range of 192.168.1.2 ~ 192.168.1.254.
3.2 Quick Installation Guide
With a Web-based utility, it is easy to configure and manage the Archer D5 AC1200 Wireless Dual
Band Gigabit ADSL2+ Modem Router. The Web-based utility can be used on any Windows,
Macintosh or UNIX OS with a Web browser, such as Microsoft Internet Explorer, Mozilla Firefox or
Apple Safari.
1. To access the configuration utility, open a web-browser and type the default address
http://tplinkmodem.net/
in the address field of the browser.
Figure 3-1
After a moment, a login window will appear, similar to the Figure 3-2. Enter admin for the
User Name a
nd Password, both in lower case letters. Then click the Login button or press the
Enter key.
Figure 3-2
