TP-Link Archer D7

Archer D7 AC1750 Wireless Dual Band Gigabit ADSL2+ Modem Router User Guide
54
 Region: Select your region from the drop-down list. This field specifies the region where the
wireless function of the modem router can be used. It may be illegal to use the wireless
function of the modem router in a region other than one of those specified in this field. If your
country or region is not listed, please contact your local government agency for assistance.

Note:
Limited by local law regulations, version for North America does not have region selection option.
 Mode
: Select the desired mode.
11an mixed - Select if you are using both 802.11a and 802.11n wireless clients.
11a/n/ac mixed - Select if you are using a mix of 802.11a, 802.11n and 802.11ac wireless
clients. It is strongly recommended that you set the Mode 11a/n/ac mixed.
 Channel: Select the channel you want to use from the drop-down List of Channel. This field
determines which operating frequency will be used. It is not necessary to change the wireless
channel unless you notice interference problems with another nearby access point.
 Channel Width: Select the channel width from the drop-down list
. The default setting is
automatic, which can adjust the channel width for your clients automatically.
 Enable SSID Broadcast: When wireless clients survey the local area for wireless networks to
associate with, they will detect the SSID broadcast by the modem router. If you select the
Enable SSID Broadcast checkbox, the wireless router will broadcast its name (SSID) on the
air.
 Enable WDS: Check this box to enable WDS. With this function, the modem router can bridge
two or more Wlans. If this checkbox is selected, you will need to set the following parameters
as shown in the figure below. Make sure the following settings are correct.
 SSID (to be bridged): The SSID of the AP your modem router is going to connect to as a
client. You can also use the search function to select the SSID to join.
 BSSID (to be bridged): The BSSID of the AP your modem router is going to connect to as a
client. You can also use the search function to select the BSSID to join.
 Scan: Click this button, you can search the AP which runs in the current channel.
 Key type: This option should be chosen according to the AP's security configuration. It is
recommended that the security type is the same as your AP's security type
 WEP Index: This option should be chosen if the key type is WEP(ASCII) or WEP(HEX). It
indicates the index of the WEP key.
