TP-Link Archer TXE75E - Page 8

06
Chapter 2 Connect to a Computer
1. Turn off your computer, unplug the power cable then remove the case panel.
2. Connect the provided Bluetooth USB cable to the adapter.
Bluetooth USB cable
Adapter
3. Locate an available PCIE X1 slot and carefully insert the adapter.
Tip:
If the bracket is not suitable for your computer, detach it from the adapter’s board and replace it with the
low-profile bracket.
