TP-Link AV1000 User Manual

Easy Management
Using tpPLC utility for advanced configurations
1. Visit https://www.tp-link.com and search for your product.
2. Find and download the compatible version of utility on its support page.
3. Install the utility and start your cinfiguration.
For technical support, the user guiude and other information visit
https://www.tp-link.com/support.
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant
provisions of directives 2014/30/EU, 2014/35/EU, 2009/125/EC, 2011/65/EU and (EU)2015/863.
The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce/
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant
provisions of the Electromagnetic Compatibility Regulations 2016 and Electrical Equipment (Safety) Regulations
2016. The original UK Declaration of Conformity may be found at https://www.tp-link.com/support/ukca
Safety Information
· Keep the device away from water, fire, humidity or hot environments.
· Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.
· The socket-outlet shall be installed near the equipment and shall be easily accessible.
· Plug the powerline devices directly into the wall outlets but not the power strips.
Please read and follow the above safety information when operating the device. We cannot guarantee that no
accidents or damage will occur due to improper use of the device. Please use this product with care and
operate at your own risk.

TP-Link AV1000 Specifications

General

Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Windows operating systems supported	Yes
Sustainability certificates	RoHS
Certification	CE
Product color	White
LED indicators	PLC, Power
Wi-Fi	No
Modulation	OFDM
Power plug	-
PowerLine standard	HomePlug AV2
Security algorithms	128-bit AES
Ethernet LAN data rates	1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Maximum operating distance	300 m
Ethernet LAN interface type	Gigabit Ethernet
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	6 W
Cables included	LAN (RJ-45)
Quantity per pack	2 pc(s)

Weight and Dimensions

Depth	72 mm
Width	131 mm
Height	42 mm
