TP-Link EAP245 User Manual

Option 1: Ceiling Rail Mounting
Option 3: Wall Mounting
Option 2: Ceiling Mounting
M3×20 Self-tapping Screws (Qty.3)
M3×28 Plastic Wall Anchors(Qty.3)
5
Connect the Ethernet cable to the
ETHERNET port on the EAP.
5
Feed the Ethernet cable through the hole
and set the ceiling tile back into place.
Connect the Ethernet cable to the ETHERNET
port.
5
Connect the Ethernet cable to the
ETHERNET port.
2
Make two small pencil marks on the wall.
Make sure the two marks are level and
98.6mm apart.
Drill a 6mm hole through the center of
each mark.
Note: We recommend that you install the EAP with the Ethernet port downward.
2
Place the mounting bracket in the center of
the ceiling tile. Mark three positions for the
screw holes and a position for the Ethernet
cable hole.
Drill three 4mm holes for the screws and a
25mm hole for the Ethernet cable at the
marked positions.
2
Use an M3×6 pan-head screw to secure
the T-rail Clip onto the ceiling rail.
1
Position the Ceiling T-rail Clip and push the
movable part toward the rail base.
1
Remove the ceiling tile.
3
Insert the plastic wall anchors into the
6mm holes and drive the self-tapping
screws into the anchors. Do not drive the
screws all the way in and leave enough
clearance to hang the EAP.
3
Secure the mounting bracket to the ceiling
tile using three M3x30 pan-head screws,
washers and wing nuts, as shown on the
left.
3
Attach the mounting bracket to the Ceiling
T-rail Clip using four M3x6 pan-head screws.
4
Hang the EAP on the screws. Make sure
the EAP is firmly seated against the wall.
4
Attach the EAP to the mounting bracket by
aligning the arrow mark on the EAP with
the arrow mark on the mounting bracket,
then rotate the EAP until it locks into place, as
shown on the left.
Ceiling T-rail Clip
M3×6 Pan-head Screws(Qty.5)
Wing Nuts (Qty.3)Washers(Qty.3) M3×30 Pan-head Screws (Qty.3)
Hole for Ethernet cable
X3
98.6mm
©2016 TP-LINK 7106506627 REV1.0.0
1
Attach the EAP to the mounting bracket
by aligning the arrow mark on the EAP
with the arrow mark on the mounting
bracket, then rotate the EAP until it locks
into place, as shown on the left.
4
Attach the EAP to the mounting bracket by
aligning the arrow mark on the EAP with the
arrow mark on the mounting bracket, then
rotate the EAP until it locks into place, as
shown on the left.

TP-Link EAP245 Specifications

General

Frequency Band	2.4GHz and 5GHz
Antenna Type	Internal
Maximum Power Consumption	12.3W
Wireless Standard	IEEE 802.11ac/n/g/b/a
Ethernet Ports	1 x Gigabit Ethernet
PoE Support	802.3at PoE
Mounting	Ceiling/Wall Mounting
Wireless Functions	Band Steering, Airtime Fairness
Wireless Security	WPA/WPA2-Enterprise, WPA-PSK/WPA2-PSK
Management	SNMP
Power Supply	802.3at PoE or 12V/2A DC
Operating Temperature	0°C to 40°C (32°F to 104°F)
Maximum Data Rate	1750 Mbps (450 Mbps at 2.4 GHz, 1300 Mbps at 5 GHz)
