TP-Link Jetstream TL-SL2428P Installation Guide

JetStream Smart Switch
02Introduction
The front panel of T1600G-52PS (TL-SG2452P) is shown as the following figure.
Figure 1-3 Front Panel of T1600G-52PS (TL-SG2452P)
Reset
Speed
PWR
SYS
PoE Max
FAN
PoE
PoE
Delivering Power Over Budget
Fault
Speed
activity1000Mbps 10/100Mbps
T1600G
-
52PS
Smart PoE Switch
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52
F
Reset LED Mode Switch
Button
LEDs 10/100/1000 Mbps RJ45 Port SFP Slot
The front panel of T1700G-28TQ is shown as the following figure.
Figure 1-4 Front Panel of T1700G-28TQ
LEDs Unit ID LED Reset 10/100/1000 Mbps RJ45 Port SFP+ Slot
The front panel of T1700X-16TS is shown as the following figure.
Figure 1-5 Front Panel of T1700X-16TS
ResetLEDs 100 M/1000 M/10 Gbps
RJ45 Port
1 G/10 Gbps SFP+ Slot
LEDs Indication
The front panel of TL-SG2218 is shown as the following figure.
Figure 1-6 Front Panel of TL-SG2218
TL-SG2218
16-Port Gigabit Smart Switch with 2 SFP Slots
LEDs Reset 10/100/1000 Mbps RJ45 Port SFP Slot
The front panel of TL-SG2210MP is shown as the following figure.
Figure 1-7 Front Panel of TL-SG2210MP
TL-SG2210MP
8-Port Gigabit Smart PoE+ Switch with 2 SFP Slots
LEDs
LED Mode
Switch Button
Reset 10/100/1000 Mbps
RJ45 Port and PoE Port
SFP Slot
