TP-Link M7000 User Manual

49
Chapter 7
Manage Your Mobile Wi-Fi
1. Download the latest firmware file for your Mobile Wi-Fi from our website
www.tp-link.com.
2. On your computer or tablet, visit http://tplinkmifi.net, and log in with the
password you set for the Mobile Wi-Fi.
3. Go to Advanced > Device > Firmware Update.
4. Select Update via the local server, click Browse to locate the downloaded file,
and then click Update.
5. Wait a few minutes for the update to complete and the mobile Wi-Fi to restart.
• To update the firmware online via web management page:
1. On your computer or tablet, visit http://tplinkmifi.net, and log in with the
password you set for the Mobile Wi-Fi.
2. Go to Advanced > Device > Firmware Update.
3. Select Update via the cloud server.
4. Click Update.
5. Wait a few minutes for the update to complete and the Mobile Wi-Fi to restart.
Note:
To download the latest firmware file, you can also click the New Version number, such as 1.0.5 in the page
above. To view update details, click Release Note.

TP-Link M7000 Specifications

General

Ethernet WAN	No
SIM card slot	Yes
3G/4G USB modem compatibility	-
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Device type	Cellular network router
Product type	Portable router
Product color	Black
LED indicators	Power, WLAN
Transmit power	20 dBmW
Output current	1 A
Output voltage	5 V
Battery capacity	2000 mAh
Power source type	Battery
Battery life (max)	8 h
USB port type	Micro-USB
Ethernet LAN (RJ-45) ports	0
4G standard	LTE-FDD
3G standards	HSPA, HSPA+, UMTS
Data network	3G, 4G, LTE
SIM card type	MicroSIM
4G bands supported	800, 850, 900, 1800, 2100, 2600 MHz
UMTS bands supported	850, 900, 2100 MHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	11b 11Mbps: -87.5dBm 11g 54Mbps: -74dBm 11n HT20 MCS7: -70dBm 11n HT40 MCS7: -68dBm
Ethernet LAN interface type	Not available
Security algorithms	SSID, WPA-PSK, WPA2-PSK
Certification	CE, RoHS
Mobile operating systems supported	Android, Windows Phone, iOS
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP
Package depth	95 mm
Package width	135 mm
Package height	50 mm
Package weight	150 g
Number of products included	1 pc(s)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	56.6 mm
Width	94 mm
Height	19.7 mm
