Omada VPN Gateway
06Appearance
LED Indication
1 - 2
(Port 1&Port 2)
Green On: Running at 10 Gbps, but no activity.
Green Flashing: Running at 10 Gbps and transmitting or receiving data.
Yellow On: Running at 1 Gbps, but no activity.
Yellow Flashing: Running at 1 Gbps and transmitting or receiving data.
Off: No device is linked to the corresponding port.
Link/Act
Yellow
Green
For 2.5G Port (Port 3):
Green On: Running at 2.5 Gbps, but no activity.
Green Off: No device is linked to the corresponding port.
Green Flashing: Running at 2.5 Gbps, and transmitting or receiving data.
Yellow On: Running at 1000/100/10 Mbps, but no activity.
Yellow Off: No device is linked to the corresponding port.
Yellow Flashing: Running at 1000/100/10 Mbps, and transmitting or receiving data.
For Gigabit Port (Port 4-11):
Green On: Running at 1000 Mbps, but no activity.
Green Off: No device is linked to the corresponding port.
Green Flashing: Running at 1000 Mbps, and transmitting or receiving data.
Yellow On: Running at 100/10 Mbps, but no activity.
Yellow Off: No device is linked to the corresponding port.
Yellow Flashing: Running at 100/10 Mbps, and transmitting or receiving data.
Interface Description
USB USB 3.0 port for USB modem and USB storage device.
Reset
Press and hold the button for 5 seconds, the SYS LED will flash quickly, indicating the
device is being reset to its factory default settings.
SFP+ WAN
(Port 1)
10G SFP+ WAN port.
SFP+ WAN/LAN
(Port 2)
10G SFP+ WAN/LAN port connecting to an SFP+ module.
By default, it is a LAN port.
You can configure it to a WAN port on the management page.
2.5G WAN/LAN
(Port 3)
2.5G RJ45 WAN/LAN port.
By default, it is a WAN port.
You can configure it to a LAN port on the management page.
Port 4
Gigabit RJ45 WAN/LAN port.
By default, it is a WAN port.
You can configure it to a LAN port on the management page
Por t 5-11
Gigabit RJ45 WAN/LAN ports.
By default, they are LAN ports connecting to local PCs or switches.
You can configure each port to a WAN port on the management page.
