Connect a PC to a LAN port of the Router with a RJ45 cable properly.1.
Set the Internet Protocol (TCP/IP) properties of the PC with the "IP address" as 2.
192.168.0.x ("x" is any number from 2 to 254), "Subnetmask" as 255.255.255.0 and
"Default gateway" as 192.168.0.1. Shown in the following figure.
Internet Protocol (TCP/IP) PropertiesFigure 5-1
To access the GUI (Graphical User Interface) of the Router, open a web browser and 1.
type the default management address http://192.168.0.1 in the address field of the
browser, then press the Enter key.
Web BrowserFigure 5-2
Enter "admin" for the default User name and Password, both in lower case letters. 2.
Then click the OK button or press the Enter key.
LoginFigure 5-3
