01Introduction
Chapter 1 Introduction
1.1 Product Overview
Designed for workgroups and departments, TP-Link JetStream Smart Switch provides wire-speed
performance and abundant L2 management features. It provides a variety of service features and
multiple powerful functions with high security.
The EIA-standardized framework and smart configuration capacity can provide flexible solutions for
a variable scale of networks. QoS and IGMP snooping/filtering optimize voice and video application.
Link aggregation increases aggregated bandwidth, optimizing the transport of business critical
data. SNMP, RMON, WEB and CLI Login bring abundant management policies. TP-LINK Gigabit Smart
Switch integrates multiple functions with excellent performance, and is friendly to manage, which
can fully meet the need of the users demanding higher networking performance.
T1500-28PCT/T1500G-10PS/T1500G-10MPS/T1600G-28PS (TL-SG2424P)/T1600G-52PS (TL-
SG2452P) is also a Power Sourcing Equipment (PSE*). Some of the RJ45 ports on the switch support
Power over Ethernet (PoE*) function, which can automatically detect and supply power with those
powered devices (PDs*) complying with IEEE 802.3af and IEEE 802.3at.
*PSE: a device (switch or hub for instance) that provides power through an Ethernet cable.
*PoE: a technology describes a system to transmit electrical power, along with data, to remote
devices over standard twisted-pair cable in an Ethernet.
*PD: a device powered by a PSE and thus consumes energy. Examples include powering network
cameras, wireless LAN access points, IP telephones, network hubs, embedded computers etc.
1.2 Appearance
■
Front Panel
The front panel of T1500-28TC (TL-SL2428) is shown as the following figure.
Figure 1-1 Front Panel of T1500-28TC (TL-SL2428)
LEDs Reset SFP Port10/100Mbps RJ45
Port
10/100/1000Mbps
RJ45 Port
The front panel of T1500-28PCT (TL-SL2428P) is shown as the following figure.
Figure 1-2 Front Panel of T1500-28PCT (TL-SL2428P)
LEDs Reset SFP Port10/100/1000Mbps
