02 Introduction
The front panel of T1500G-10MPS is shown as the following figure.
Figure 1-3 Front Panel of T1500G-10MPS
LEDs LED Mode
Switch Button
Reset 10/100/1000Mbps
RJ45 Port and PoE Port
SFP Port
The front panel of T1600G-18TS (TL-SG2216) is shown as the following figure.
Figure 1-4 Front Panel of T1600G-18TS (TL-SG2216)
LEDs Reset 10/100/1000Mbps RJ45 Port SFP Port
The front panel of T1600G-28TS is shown as the following figure.
Figure 1-5 Front Panel of T1600G-28TS
10/100/1000Mbps RJ45 PortLEDs Reset SFP Port
The front panel of T1600G-28PS is shown as the following figure.
Figure 1-6 Front Panel of T1600G-28PS
LEDs Reset 10/100/1000Mbps
RJ45 Port
SFP PortLED Mode
Switch Button
The front panel of The T1600G-52TS (TL-SG2452) is shown as the following figure.
Figure 1-7 Front Panel of T1600G-52TS (TL-SG2452)
Reset
PWR
SYS
T1600G
-
52TS
Smart Switch
F
