6. Mount your camera to the side so that movement goes across the len’s eld of view to better trigger motion detection and AI detection.
*Do not mount facing the direction of movement.
7. For optimal detection performance, we recommend mounting the camera 7-10 ft (2-3 m) above the ground.
*You can adjust the sensitivity in Camera Settings > Detection > Wake-up Sensitivity.
The FOV and PIR detection zone shown is based on camera mounted at 7.2 ft/2.2 m.
PIR Detection Zone (Default Wake-up Sensitivity*)
PIR Detection Zone (Highest Wake-up Sensitivity*)
Camera Field of View
+
23 ft / 7 m
(Default Wake-up Sensitivity)
30 ft / 9 m
(Highest Wake-up Sensitivity)
Height:
7-10 ft
(2-3 m)
