2
Power: Solid light
WLAN: Flashing
Power on all your network devices and then check to see if the LEDs of the
Router display normally as the diagram below describes.
Note
If the LEDs display abnormally, please check to see if all the cable
connectors (power adapter, phone line and Ethernet cable) are well
connected to your device. With the phone line well connected, if the ADSL
LED turns off after flashing, please contact your ISP to ensure that you
internet connection is active.
Plug the provided Power Adapter
into the Power jack on the back of
the Modem Router and the other
end to a standard electrical wall
socket.
To configure the device, you can either run the setup CD-ROM (method one),
or run the Web based Quick Setup Wizard (method two). TP-LINK strongly
recommends that you run the setup CD-ROM.
Note
LAN: Flashing or solid light if
corresponding port is connected
ADSL: Flashing or solid light
To Next Page
