User Manual
Code: TL-SG1016D
SWITCH TL-SG1016D 16-PORT TP-LINK
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: delta-opti@delta.poznan.pl; tel: +(48) 61 864 69 60
2022-06-03 TL-SG1016D 2/3
The device is widely used in small computer networks, neighborhood
networks. It has built-in the Auto MDI/MDIX function, which does not
bother the installer about the problem of straightforward or crossover
cables.
LAN ports: 16x (RJ45) 10/100/1000 Mb Auto-Negotiation
Management via WWW / console:
Housing: RACK 19", 1U
LED diodes: Power, Link/Act
Transmission speed: Full Duplex: IEEE802.3x,Half Duplex: Back Pressure
MAC addresses table: 8k
Certificates: FCC Class B, CE Mark
Power supply: 100 ... 240 V AC / 0.6 A
Weight: 1.48 kg
Dimensions: 295 x 184 x 45 mm
Manufacturer / Brand: TP-LINK
Guarantee:
3 years
Front view:
Rear view:
