JetStream L2/L2+ Managed Switch
04 Introduction
The front panel of TL-SG3452X is shown as the following figure.
LED
1G RJ45 Port
SFP+ Slot
Console Port
(RJ45/USB)
ConsoleConsole(USB)
TL-SG3452X
L2+ Managed Switch
1000Mbps
10/100Mbps
SFP+
activity
10Gbps
1Gbps
The front panel of TL-SG3452XP is shown as the following figure.
LED
1G RJ45 Port
SFP+ Slot
Console Port
(RJ45/USB)
Speed
PWR
SYS
PoE Max
FAN
PoE
Console(USB)Console(RJ45)
TL-SG3452XP
L2+ Managed PoE+ Switch
PoE
Delivering Power
Over Budget
Fault
Speed
activity1000Mbps
10/100Mbps
activity10Gbps
1Gbps
SFP+
