TP-Link TL-WA750RE User Manual

TL-WA750RE
150Mbps Universal WiFi Range Extender User Guide
6
Chapter 3 Quick Installation Guide
This chapter will guide you to configure your PC to communicate with the Range Extender and to
configure and manage the TL-WA750RE 150Mbps Universal WiFi Range Extender easily with a
Web-based utility.
With a Web-based utility, it is easy to configure and manage the TL-WA750RE 150Mbps Universal
WiFi Range Extender. The Web-based utility can be used on any Windows, Macintosh or UNIX
OS with a Web browser, such as Microsoft Internet Explorer, Mozilla Firefox or Apple Safari.
1. To access the configuration utility, open a web-browser and type in the domain name
http://tplinkextender.net in the address field of the browser.
Figure 3-1 Login to the Range Extender
After a moment, a login window will appear as shown in Figure 3-2. Enter admin for the User
Name and Password (both in lower case letters). Then click OK or press Enter.
Figure 3-2 Login Windows

Note:
If the above screen does not prompt, it means that your web-browser has been set to a proxy. Go
to Tools menu > Internet Options > Connections > LAN Settings, in the screen that appears,
cancel the Using Proxy checkbox, and click OK to finish it.

TP-Link TL-WA750RE Specifications

General

Type	Network transmitter & receiver
Maximum transfer distance	- m
Mac operating systems supported	Yes
Windows operating systems supported	Windows 2000, Windows 98SE, Windows NT, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Product color	White
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN (RJ-45) ports	1
External power adapter	No
Power consumption (typical)	3 W
Cables included	LAN (RJ-45)
Operating temperature (T-T)	32 - 104 °F
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	65.8 mm
Width	110 mm
Height	75.2 mm
