5
Chapter 1
Get to Know About Your Router
The following parts (view from left to right) are located on the rear panel.
Item Description
Power Port For connecting the router to a power socket via the provided power adapter.
WAN Port For connecting to a DSL/Cable modem, or an Ethernet port.
Ethernet Ports (1/2/3/4) For connecting your PCs or other wired network devices to the router.
WPS/RESET Button
To enable the WPS function, press this button for 1 second. If you have a
WPS-supported device, you can press this button to quickly establish
connection between the router and the client device and automatically
configure wireless security for your wireless network.
Press and hold this button for more than 5 seconds until the Internet LED
blinks to reset the router to its factory default settings.
Antennas
Used for wireless operation and data transmitting. Upright them for the best
Wi-Fi performance.
