9
Chapter 2
Connect to the Internet
2 ) Immediately press the WPS button on your router.
WLAN
On
TP-Link
HomeNetwork
Oce
TP-Link_123
TP-Link_ABC
MyHome
Test
WPS/
RESET
2 3WAN 1 4
POWER
Close to
3. Enter http://tplinkwifi.net in the address bar of a web browser. Use admin for
username and password, and then click Login.
Note:
If the above screen does not pop-up, it means that your IE Web-browser has been set to a proxy. Go to menu Tools
> Internet Options > Connections > LAN Settings, in the screen that appears, untick the Using Proxy checkbox,
and click OK.
4. After successfully login, select Wireless Router and follow the Quick Setup to set
up the internet connection.
5. Enjoy! For wireless devices, you may have to reconnect to the wireless network if you
have customized the SSID (wireless name) and password during the configuration.
2. 2. 2. WISP Mode
This mode connectes to the ISP network wirelessly in areas without wired service.
