TP-Link TL-WR842N

TL-WR842N
300Mbps Multi-Function Wireless N Router User Guide
- 132 -
Appendix C: Specifications
General
Standards
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a, IEEE
802.11e, IEEE 802.11i, IEEE 802.1X, IEEE 802.3X, IEEE 802.3,
IEEE 802.3u, IEEE 802.3ab
Protocols
TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP
Ports
One 10/100M Auto-Negotiation Internet RJ45 port
Four 10/100M Auto-Negotiation LAN RJ45 ports supporting Auto
MDI/MDIX
One USB port supporting storage/FTP/Media/Print Server
Cabling Type
10BASE-T: UT P category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
LEDs
Safety & Emissions
FCC, CE
Wireless
Frequency Band*
2.4
～
2.4835GHz
Radio Data Rate
11b：1/2/5.5/11Mbps
11g：6/9/12/18/24/36/48/54Mbps
11n
：
up to 300Mbps
Frequency Expansion
DSSS (Direct Sequence Spread Spectrum)
Modulation
DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM
Security
WEP, WPA/W PA2-Enterprise, WPA2 /WPA-Personal
Sensitivity @PER
270M: -68dBm@10% PER;
130M: -68dBm@10% PER
108M: -68dBm@10% PER;
54M: -68dBm@10% PER
11M: -85dBm@8% PER;
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Antenna Gain
5dBi External Antenna
Environmental and Physical
Tem perature.
Operating : 0
℃
~40
℃
(32
℉
~104
℉
)
Storage: -40
℃
~70
℃
(-40
℉
~158
℉
)
Humidity
Operating: 10% - 90% RH, Non-condensing
Storage: 5% - 90% RH, Non-condensing
* Only 2.412GHz~2.462GHz is allowed to be used in USA, which means only channel 1~11 is available for
American users to choose.
