TP-Link WPA7617 User Manual

5
Chapter 1
Get to Know Your Powerline Extender
Name Status Indication
Power
On/Off The powerline extender is on or off.
Blinking
Quickly: Pairing is in progress.
Slowly: Power-saving Mode is on.*(TL-PA7017P Only)
Powerline
On
The powerline extender is connected to the powerline
network and is in a suitable location.
Off
The powerline extender is not connected to any
powerline network.
Ethernet
On
At least one Ethernet port is connected to a powered-on
device.
Off No Ethernet port is connected to a powered-on device.
Wireless
On The wireless function is enabled.
Off The wireless function is disabled.
Blinking
Slowly: The powerline extender is cloning wireless
network settings from the main router.
Quickly: The powerline extender is syncing wireless
network settings.
1. 3. 2. Physical Interface
Plug
Pair/Reset Button
Ethernet Port
Wi-Fi Button
LED ON/Off Button

TP-Link WPA7617 Specifications

General

Ethernet Ports	1 Gigabit Ethernet Port
Wi-Fi Standards	IEEE 802.11b/g/n
Operating Temperature	0°C to 40°C (32°F to 104°F)
Operating Humidity	10% to 90% Non-condensing
Storage Humidity	5% to 90% Non-condensing
Frequency Band	2.4GHz
Maximum Speed	1000 Mbps (Powerline), 300 Mbps (Wi-Fi)
Powerline Networking	Yes
Plug Type	EU, UK, US
Type	Powerline Wi-Fi Extender
Wi-Fi Speed	Up to 300 Mbps on 2.4GHz
Range	Up to 300 meters over powerline
Security	128-bit AES Encryption
Standards and Protocols	HomePlug AV2, IEEE 1901, IEEE 802.3, IEEE 802.3u
Button	Pair Button, Reset Button
Power Consumption	Maximum: 6.7W
LED Indicator	Power, Powerline, Wi-Fi, Ethernet
Compatibility	Compatible with all HomePlug AV and AV2 standard powerline adapters
Product Type	Powerline Wi-Fi Extender
Antennas	2 Internal Antennas
