4 Technical data
4.1 Power supply
Rated Voltage ........................................................
24 V DC
Power consumption .............................................
≤ 3.5 W
4.2 Mechanical characteristics
Measuring length ..........................................
50…3600 mm, in steps; see nameplate
Resolution ................................
≥ 0.001 mm; see nameplate
Linearity error ................................................
± 0.10 mm <= 1500 mm / ± 0.15 mm > 1500 mm
Reproducibility ................................
0.005 mm
Hysteresis ......................................................
0.02 mm <= 1500 mm / 0.1 mm > 1500 mm
Temperature coefficient ...............................
< 8 μm/°C <= 500 mm / < 15 ppm/°C > 500 mm
Analog variant ................................
< 40 ppm/°C, total measuring range
Straight line velocity .....................................
no restrictions
Mounting position ................................
no restrictions
Material - Measuring body ...........................
Aluminium extruded profile
Magnet ................................
...........................
Slider, other on request
4.3 Environmental conditions
Vibration, DIN EN 60068-2-6
≤ 100 m/s
2
, sine 50-2000 Hz
Shock, DIN EN 60068-2-27
..........................
≤ 1000 m/s
2
, half-sine 11ms
EMC
Immunity to disturbance, DIN EN 61000-6-2
Transient emissions, DIN EN 61000-6-3
Working temperature ..................................
-20 °C…+60 °C
Storage temperature ................................
-30 °C…+85 °C, dry
Relative humidity, DIN EN 60068-3-4 .........
98 %, non-condensing
1
Protection class ................................
IP64: Degrees of protection provided by enclosures
according to DIN EN 60529
1
Observe instructions for safe use, see chapter 2.12 on page 16
