TRANSISTOR BC549C 72-TBC549C 1 TR1
8-WAY SOCKET 72-SOCKET-8W 1 FOR IC1
IC RC4558P 72-IC-RC4558P 1 IC1
POT A 1MEG 73-POT-A1M 1 P1
POT A 250K 73-POT-A250K 2 P2 P4
POT A 25K 73-POT-A25K 1 P5
POT A25K PULL SWITCH 73-POT-A25K-PS 1 P3
MINI TOGGLE SWITCH 73-SWT-M-TGL-PCB 4 SW1 SW3 SW4 SW5
2-WAY HEADER 0.1” 72-HEAD-2W 4 HP1-HP4 (SEE NB1)
8-WAY HEADER 0.2” 72-HEAD-8W 1 PL1
VALVE BASE 9-WAY 73-VAL-SOCKET 2 VT1 VT2
XLR PLUG NEUTRIK 73-XLR-PCB-M-N 1 XLR1
JACK SOCKETS 72-SKT-JCKBNBG 2 SK1 SK2
FLYLEAD C00-FLY-HEATER 1 ACROSS HP1-HP4
SIGNAL LEAD LOOM-00275 1 From L/0(F) to PC00009
SIGNAL LEAD LOOM-00276 1 From send/return to PC00009
LEAD FOR LAMP LOOM-00277 1 From PL3 to 6.3V lamp
N.B.1 The four 2-way headers are fitted with their small face to the left. This is
with the pots facing you.
