TRACE ELLIOT V-TYPE - Electrical Parts List

C12-PCB-VTYP-C/Hx1.
V-TYPE COMBO/HEAD PREAMP MAIN BOARD.
ISSUE 1 INSERTION LIST. ANDY EWEN 11/8/98.
DESCRIPTION PART CODE QTY WHERE USED
PCB PC00008 ISSUE 2 73-PCB-PC00008 1
ZENER DIODE 27V 72-D-BZX55C27V 1 ZD1
DIODE 72-D-IN4007 10 D1-D10
RES 2.5W 4K7 72-RWW4K7-2.5W 1 R35
RES 2W 100K 72-RC100K-2W 4 R8 R10 R17 R20
RES 1/2W 10K 72-RC10K-.5W 2 R9 R36
ZERO OHM LINK 72-RCZERO 28 AS MARKED
RES 1/4W 100K 72-RM100K 2 R2 R5
RES 1/4W 100R 72-RM100R 1 R40
RES 1/4W 10K 72-RM10K 1 R24
RES 1/4W 10M 72-RM10M 1 R14
RES 1/4W 150K 72-RM150K 1 R23
RES 1/4W 1K5 72-RM1K5 3 R6 R16 R18
RES 1/4W 1M 72-RM1M 7 R3 R4 R7 R12 R15 R21 R22
RES 1/4W 27K 72-RM27K 1 R1
RES 1/4W 330K 72-RM330K 1 R13
RES 1/4W 47K 72-RM47K 8 R25-R32
RES 1/4W 560K 72-RM560K 1 R11
RES 1/4W 560R 72-RM560R 2 R33 R34
RES 1/4W 5K6 72-RM5K6 1 R37
RES 1/4W 8K2 72-RM8K2 1 R19
CAP 1uF POLY BOX 72-C1-250VP 1 C2
CAP 1uF ELEC RADIAL 72-C1-63VER 2 C14 C15
CAP 10uF ELEC RADIAL 72-C10-35VER 2 MOD ACROSS R28 & R29
+ve legs nearest IC1.
CAP 10uF ELEC RADIAL 72-C10-63VER 2 C16 C17
CAP 1000uF ELEC RAD. 72-C1000-63VER 1 C22
CAP 100N POLY BOX 72-C100N-250VP 5 C4 C24 C25 C26 C27
CAP 100P CER DISC 72-C100P-100VCD2 2 C18 C28
CAP 150P CER DISC 72-C150P-50VCD 1 C8
CAP 200P Polystyrene 72-C200P-630VPA 1 C3
CAP 22uF ELEC AXIAL 72-C22-450VEA 2 C20 C21
CAP 22N POLY BOX 72-C22N-400VP 2 C12 C13
CAP 47uF ELEC RADIAL 72-C47-63VER 2 C9 C10
CAP 470uF ELEC RAD. 72-C470-63VER 1 C23
CAP 470N POLY BOX 72-C470N-250VP 1 C11
CAP 47N POLY BOX 72-C47N-100VP 1 C1
CAP 47N POLY BOX 72-C47N-400VP 2 C5 C7
CAP 4N7 POLY BOX 72-C4N7-400VP 1 C6
CAP 100uF ELEC RAD. 72-CAP-100400V 1 C19
