61
Place bolt through rear swing arm
located just in front of rear shock.
62
Start bolt into fender bracket by
hand. Then, tighten firmly with a
10mm wrench.
NOTE: Repeat Steps 60-62 for the other side.
63
Slide rear wheel onto rear axle with
the valve stem to the outside. The
tread on top of the tire should be pointing
forward.
64
Install large washer and castle nut on
axle.
65
Tighten nut making sure to align with
holes in axle.
66
Install cotter pin. Bend and clip off
excess clip.
Repeat Steps 63-66 for the other side.
