Blazer4 150X/200X Set up instruction
5
Pic.7
2.5 Assemble the rear wheels (pic.8): screw the castle nut M16x1.5 tightly
with 98-103NM, put on the cotter pin 3X40, lift the frame to install
the wheel (please pay attention to the right direction of wheel
installation as shown in the pic. 8), screw the tire nuts tightly with
torque 37-44NM, cover the hub cover.
Pic.8
