25
Install the top bolt & washer first.
Start the threads but do not tighten.
26
Now, install the bottom bolt and
washer from the front.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
27
Install the second washer and nut on
the bottom bolt.
NOTE: DO NOT TIGHTEN THE HARDWARE.
GOKARTMASTERS.COM
28
Repeat steps 20-27 for the driver’s
side bar.
29
Locate the top bar weldment assem-
bly.
GOKARTMASTERS.COM
GOKARTMASTERS.COM
30
Locate 4 large bolts and 4 chrome
cupped washers.
GOKARTMASTERS.COM
