Heater Pressure Drop Table
Airflow
CFM
Number of Elements Heater Elements
1 2 Heater Model No. of Heater Elements
Pressure Drop — (“W.C.)
BAYHTRA505BRKA 1
600 0.01 0.03 BAYHTRA508BRKA 2
700 0.01 0.03 BAYHTRA510BRKA 2
800 0.01 0.03
900 0.01 0.03
1000 0.01 0.03
1100 0.01 0.03
1200 0.01 0.04
1300 0.02 0.04
1400 0.02 0.04
