39
System Matched with: Indoor Unit Model No. Outdoor Unit Model No. Subcooling
16-18 SEER HP GAM5B0A24M21*
4TWR6024A*, 4TWX6024G*
4A6H6024G*, 4TWR7024A*
4TWX8024A*, 4A6H7024A*
9°
All other matches must be charged per the nameplate charging instructions.
20.2 Adjustments for 2-Stage outdoor HP models
16 SEER Heat Pump Models
OD MODEL ID MODEL SPEED TAP SYSTEM STAGE CFM ESP
4TWR6024A*4
4TWX6024G*4
4A6H6024G* 4
GAM5B0A24M21*
4 H 800 0.333
3 L 750 0.293
4TWR6024A*
4TWX6024G*
4A6H6024G*
GAM5B0B30M21*
3 H 750 0.383
2 L 665 0.301
4TWR6036A*
4TWX6036E*
4A6H6036E*
GAM5B0B36M31*
4 H 1150 0.500
3 L 1005 0.382
4TWR6048A*
4TWX6048G*
4A6H6048G*
GAM5B0C42M31*
4 H 1375 0.468
3 L 1235 0.378
4TWR6048A*
4TWX6048G*
4A6H6048G*
GAM5B0C48M41*
4 H 1575 0.400
2 L 1420 0.325
4TWR6060A*
4TWX6060E*
4A6H6060E*
GAM5B0C60M51*
3 H 1700 0.390
2 L 1645 0.365
17/18 SEER Heat Pump Models
OD MODEL ID MODEL SPEED TAP SYSTEM STAGE CFM ESP
4TWR7024A* 4
4TWX8024A* 4
4A6H7024A* 4
GAM5B0A24M21*
4 H 800 0.333
3 L 750 0.293
4TWR7024A*
4TWX8024A*
4A6H7024A*
GAM5B0B30M21*
3 H 750 0.383
2 L 665 .0301
4TWR7036A*
4TWX8036A*
4A6H7036A*
GAM5B0B36M31*
4 H 1150 0.500
3 L 1005 0.382
4TWR7048A*
4TWX8048A*
4A6H7048A*
GAM5B0C48M41*
4 H 1575 0.400
2 L 1420 0.325
4TWR7060A*
4TWX8060A*
4A6H7060A*
GAM5B0C60M51*
3 H 1700 0.390
2 L 1645 0.365
NOTES
1) Speed Tap settings must be changed for two stage operation
2) Speed Tap settings listed are for the rated ESP, settings may be different depending on your ESP
3) Minimum airflow for electric heat must be maintained. (High Stage)
4) Subcooling must be adjusted to 9°F for this match
