6
Section 3. Unit Preparation
3.1 Prepare The Unit For Installation
STEP 1 - Check for damage and report promptly to the
carrier any damage found to the unit.
Note: If the unit must be transported in a horizontal posi-
tion, it must be laid on its back (marked “REAR” on carton).
Note: After the unit is removed from the carton, release
pressure from the coil to verify coil is pressurized and leak
free.
3.2 Unit Accessories
Accessory Number Description Fits Cabinet Size
BAYEAAC04BK1 Electric Heater, 4kW, Breaker, 24V Control, 1 Ph A to C
BAYEAAC04LG1 Electric Heater, 4kW, Lugs, 24V Control, 1 Ph A to C
BAYEAAC05BK1 Electric Heater, 5kW, Breaker, 24V Control, 1 Ph A to C
BAYEAAC05LG1 Electric Heater, 5kW, Lugs, 24V Control, 1 Ph A to C
BAYEAAC08BK1 Electric Heater, 8kW, Breaker, 24V Control, 1 Ph A to C
BAYEAAC08LG1 Electric Heater, 8kW, Lugs, 24V Control, 1 Ph A to C
BAYEAAC10BK1 Electric Heater, 10kW, Breaker, 24V Control, 1 Ph A to C
BAYEAAC10LG1 Electric Heater, 10kW, Lugs, 24V Control, 1 Ph A to C
BAYEAAC10LG3 Electric Heater, 10kW, Lugs, 24V Control, 3 Ph A to C
BAYEABC15BK1 Electric Heater, 15kW, Breaker, 24V Control, 1 Ph B to C
BAYEABC15LG3 Electric Heater, 15kW, Lugs, 24V Control, 3 Ph B to C
BAYEABC20BK1 Electric Heater, 20kW, Breaker, 24V Control, 1 Ph B to C
BAYEACC25BK1 Electric Heater, 25kW, Breaker, 24V Control, 1 Ph C
BAYSUPFLGAA Supply Duct Flange A A
BAYSUPFLGBA Supply Duct Flange B B
BAYSUPFLGCA Supply Duct Flange C C
BAYRETFLGAA Return Duct Flange A A
BAYRETFLGBA Return Duct Flange B B
BAYRETFLGCA Return Duct Flange C C
BAYSRKIT100A Side Return Kit A to C
BAYFLR1620A High Velocity Filter Kit, 16” X 20’ X 1” (10 filters) A
BAYFLR2020A High Velocity Filter Kit, 20” X 20’ X 1” (10 filters) B
BAYFLR2220A High Velocity Filter Kit, 22” X 20’ X 1” (10 filters) C
TASB175SB Plenum Stand with Integrated Sound Baffle A A
TASB215SB Plenum Stand with Integrated Sound Baffle B B
TASB235SB Plenum Stand with Integrated Sound Baffle C C
MITISRKIT1620 Side Return Kit with 16” x 20” Filter A to C
BAYFRKIT175 Front Return Kit for 17.5” Cabinet A
BAYFRKIT210 Front Return Kit for 21.0” Cabinet B
BAYFRKIT235 Front Return Kit for 23.5” Cabinet C
BAYBAFKT175 Sound Baffle Kit for 17.5” Cabinet A
BAYBAFKT210 Sound Baffle Kit for 21.0” Cabinet B
BAYBAFKT235 Sound Baffle Kit for 23.5” Cabinet C
TASSBK175 Sound Baffle Kit for 17.5” Cabinet A
TASSBK215 Sound Baffle Kit for 21.0” Cabinet B
TASSBK235 Sound Baffle Kit for 23.5” Cabinet C
BAYICSKIT01A Internal Condensate Switch Kit A to C
BAYHHKIT001A Horizontal Hanger Kit A to C
BAYUVCLK001A UVC Lights A to C
BAYLVKIT100A Low Voltage Conduit Entry Kit A to C
BAYSPEKT200A Single Point Power Entry Kit B to C
BAYWAAA05SC1AA Hydronic heater, A cabinet, no control, slide-in A
BAYWABB07SC1AA Hydronic heater, B cabinet, no control, slide-in B
BAYWACC08SC1AA Hydronic heater, C cabinet, no control, slide-in C
BAYWACC11SC1AA Hydronic heater, C cabinet, no control, external C
BAYATXV1836 R-22 TXV conversion kit GAM5B0A18-24
BAYATXV4248 R-22 TXV conversion kit GAM5B0B30-36,GAM5B0C42
BAYATXV6060 R-22 TXV conversion kit GAM5B0C48-60
BAYINSKT175A
Solcoustic® Liner Kit - 17.5" Cabinet
A
BAYINSKT215A
Solcoustic® Liner Kit - 21.5" Cabinet
B
BAYINSKT235A
Solcoustic® Liner Kit - 23.5" Cabinet
C
BAYCNDPIP01A 3/4” PVC Threaded Pipe Kit Foam Seal (10 per box) A to C
Table 3.1
